1. Usage Instructions
-
Do not use this product together with other medical devices.
-
Do not use this product immediately after eating or after consuming alcohol.
-
Keep children and pets away from the product. Do not insert fingers or any other objects into the gaps of the machine.
-
This product is designed for use by one person at a time. Do not allow two or more people to use it simultaneously.
-
Before use, check that your power supply voltage matches the requirements of the product.
-
In the event of a power outage, or after extended periods without use, turn off the power switch and unplug the power cord.
-
If water comes into contact with the product or the remote control, stop using it immediately.
-
If any accessory is damaged or produces an unusual sound, stop use immediately.
-
If you experience dizziness, numbness, pain, or any other discomfort during use, stop immediately.
-
Do not use the product during a sudden power failure or during a thunderstorm.
-
Maintain your balance while using the product to avoid falling.
2. Maintenance and Storage
-
Store the machine in a dry, dust-free location.
-
Do not store the unit near heaters or open flames. Do not expose it to direct sunlight for extended periods.
-
Do not clean the machine with solvents such as thinner, volatile oils, or bleach.
-
The pedal panel and outer casing may be cleaned with a damp cloth. Do not pour liquids onto the product, as this may cause a short circuit or other faults.
-
Clean the remote control with a dry cloth only, to prevent malfunction.
3. Important Safety Information
-
Use a properly grounded power socket. Avoid sharing the socket with other electrical equipment.
-
If the power cable needs to be replaced, use a cable that includes a grounding function.
-
After use, turn off the power supply and unplug the device.
-
When unplugging, hold the plug itself and pull gently. Do not pull on the cable.
-
Before use, check that the product is placed on a stable, level surface.
-
The vibration speed can be adjusted by the user according to personal preference.
-
Use indoors only, in a dry environment. Do not splash water on the machine, and do not place foreign objects on it.
-
This product must not be used by children, pregnant women, elderly individuals, or people with physical disabilities.
-
Do not allow children to play with or touch the unit while it is in use.
-
If you feel unwell, stop using the product and consult a medical professional.
-
If you have a pre-existing medical condition, consult a medical professional before use.
-
If the machine behaves abnormally during use, stop immediately and contact your local dealer. Only qualified maintenance personnel should inspect or repair the unit — do not attempt to open or repair it yourself, as this may result in unexpected hazards.
-
Any built-in fat or heart-rate measurement is not a medical-grade test and may not be fully accurate. This data is for reference purposes only.
-
Exercise particular caution if you: have high blood pressure; use a pacemaker or other implanted electronic device; have a prosthetic limb or limited leg mobility; or have any condition affected by vibration or strenuous movement. Consult a doctor before use if any of these apply to you.
-
For safety, turn off the power supply whenever the machine is not in use.
4. Bluetooth Music Streaming
To connect via Bluetooth:
-
Open the Bluetooth pairing settings on your device.
-
Locate a network named "Bluetooth," select it, and pair with your device.
-
Once connected, music can be played and controlled from your device, and will play through the machine's speakers.
-
Alternatively, use the remote control to adjust volume or play/pause your music.
5. Product Specifications
|
Specification |
Details |
|
Product Name |
Vibrating Plate |
|
Model |
TD-331 |
|
Rated Voltage and Frequency |
100–240V, 50/60Hz |
|
Rated Power |
150W |
|
Rated Operating Time |
10 minutes |
|
Swing Amplitude |
10 mm |
|
Standards |
GB4706.1-2005, GB4706.10-2008 |
|
Included Items |
Host unit ×1, Power cable ×1, Instruction manual ×1, Remote control ×1 |
Technical parameters are subject to change without prior notice.
6. Troubleshooting
|
Issue |
Possible Cause |
Solution |
|
Machine does not turn on |
Power switch is not turned on |
Turn on the power switch |
|
Machine does not turn on |
Poor contact between plug and socket |
Check the outlet and ensure a secure connection |
|
Remote control does not respond |
Battery is missing or depleted |
Insert the battery correctly, or replace it |
|
Remote control does not respond |
Remote is too far from the machine |
Move closer to the machine and try again |
|
Machine makes a clicking or knocking sound |
This is a normal sound produced by the mechanical components |
No action needed — this is normal |
|
Indicator light stays on briefly after switching off |
Residual electrical charge in the controller has not yet discharged |
No action needed |
|
Indicator light turns on without pressing the power button |
Stepping on the plate can generate a small induction current in the motor |
This is a normal phenomenon — no action needed |
|
Power cord is damaged, or the unit emits an odor or smoke |
Internal fault |
Stop use immediately and contact a repair technician |
